Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

1 conjunto/conjuntos
MOQ
negotiable
preço
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Características Galeria Descrição de produto Peça umas citações
Características
Especificações
Nome do Produto: Compressor de ar de parafuso, Máquina de compressor de ar
Nome: Compressor de ar diesel do parafuso
Potência: 410 kW
Fonte de energia: Diesel
Pressão: 21-25bar/21-34bar
Consumo de ar: 31-29 m2/min 36,5-32 m2/min
Velocidade: 1600/1400 rpm 1830/1400 rpm
Capacidade do tanque de combustível: 700 litros
Capacidade do óleo de lubrificação: 120 litros
Método de arrefecimento: Ar/refrigerar de água disponível
Aplicação: Projeto de mineração, carvão, minério
Tipo: - Vai-te lixar.
Componentes essenciais: PLC, Vaso de pressão, Motor, Motor, Bomba, Rolamento
Configuração: Fixação
dimensão (c*l*a): 4100*1800*2050mm
Peso: 5600kg
Destacar:

Diesel Screw Air Compressor

,

Rotary Screw Air Compressor

,

Rotary Screw Drive Air Compressor

Informação básica
Lugar de origem: Zhejiang, China
Marca: SANROCK
Certificação: CE ISO 9001:2015
Número do modelo: Personalizado
Condições de Pagamento e Envio
Detalhes da embalagem: Embalagem nua para máquinas, caixa de madeira para peças sobressalentes, ou a demanda do cliente.
Tempo de entrega: 18-25 dias úteis
Termos de pagamento: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Habilidade da fonte: 5000Sets/Sets por mês
Descrição de produto

screw air compressor used with water well drilling rig
This specialized rotary screw air compressor is engineered to deliver high-efficiency compressed air supply for water well drilling operations.
Featuring robust twin-screw technology, to power down-the-hole hammers and rotary drilling systems. superior cooling and lubrication for extended duty cycles in harsh drilling environments.
Integrated with vibration-resistant components and heavy-duty filtration systems, this compressor maintains high performance under dust and high-temperature conditions.
Automatic load/unload controls and energy-saving VFD options enhance fuel efficiency for mobile drilling rig configurations. With protection rating and corrosion-resistant coatings, it meets rigorous drilling industry standards for reliability in borewell construction and geothermal drilling applications.

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 0Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 1

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 2

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 3



Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 4Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 5

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 6Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 7

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 8

Products Description

Brand Name:Sanrock
Product name: screw air compressor
Compressor
Pressure (bar)
21-25 21-34
Air consumption (m²/min)
31-29 36.5-32
Lubricating oil capacity(L)
120
Dual transformation
Dual
Engine
brand
Cummins
Mode
QSZ 13-C550
Power (kw)
410
Max working/idle speed (rpm
1600/1400 1830/1400
Cylinder No
6
Total displacement(L)
13
Emission standard
Stage Ⅲ
Fuel tank capacity (L)
700
Unit
xhaust port specifications *Quant
G2*1&G3/4*1
Wheel specifications *Quantity
Skid mounted
Noise[Db(A)]
85±3
Dimension (mm
4100x1800x2050
Weight (kg)
5600


Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 9

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 10Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 11Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 12
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 13Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 14
